Atlas of Urban Expansion

Population

The Population of Modesto in 2014 was 458,146, increasing at an average annual rate of 2.2% since 2000. The population of Modesto in 2000 was 334,840, increasing at an average annual rate of 4.5% since 1992, when its population was 232,879.

Urban Extent

The Urban Extent of Modesto in 2014 was 32,976 hectares, increasing at an average annual rate of 2.9% since 2000. The urban extent in 2000 was 21,850 hectares, increasing at an average annual rate of 5.6% since 1992, when its urban extent was 13,937 hectares.

• 1992
• 2000
• 2014

•
• Urban Extent
• Urban Built-up
• Suburban Built-up
• Rural Built-up
• Urbanized Open Space
•
• Exurban Area
• Exurban Built-Up Area
• Exurban Open Space
•
• Rural Open Space
• Rural Open Space

Density

Built-up Area Density in Modesto in 2014 was 20 persons per hectare, decreasing at an average annual rate of -0.8% since 2000. The built-up area density in 2000 was 23 persons per hectare, decreasing at an average annual rate of -2% since 1992 when the built-up area density was 26.55 persons per hectare.

The Urban Extent Density in Modesto in 2014 was 14 persons per hectare, decreasing at an average annual rate of -0.7% since 2000. The urban extent density in 2000 was 15 persons per hectare, decreasing at an average annual rate of -1.1% since 1992 when the urban extent density was 17 persons per hectare.

Composition of Added Area

A total of 7,881 hectares of built-up area was added to the Modesto urban extent between 2000 and 2014. Of that added built-up area, 31% was Infill, 27% was Extension, 0% was Leapfrog, and 41% was Inclusion. A total of 6,083 hectares of built-up area was added to the urban extent between 1992 and 2000. Of that added built-up area, 35% was Infill, 19% was Extension, 0% was Leapfrog, and 46% was Inclusion.

• 1992–2000
• 2000–2014

• Built-up Area
  1992
• Infill
• Extension
• Leapfrog
• Inclusion

Roads

Average road width in the Modesto 1990-2014 expansion area was 10.21 meters, compared to 10.59 meters in its pre-1990 area.

The share of built-up area in Modesto occupied by roads in the 1990-2014 expansion area was 29%, compared to 25% in the pre-1990 area.

• Pre 1990
• 1990 – 2014

Arterial Roads

The density of arterial roads in Modesto's 1990-2014 expansion was 1.54 km/km2, compared to 1.91 km/km2 in its pre-1990 area.

The share of built-up area within walking distance of an arterial road in Modesto's 1990-2014 expansion area was 92%, compared to 96% in the pre-1990 area.

• 1992
• 2014

Blocks and Plots

Average block size in Modesto's 1990-2014 expansion area was 5.1 hectares, compared to 2.5 hectares in its pre-1990 area.

• Pre 1990
• 1990 – 2014
